EonStor GS 3000 Gen3

• GS 3012 G3
• GS 3016 G3
• GS 3024 G3
• GS 3040 G3
• GS 3060 G3
• GS 3090 G3

• 2U 12-bay
• 3U 16-bay
• 4U 24-bay
• 4U 40-bay
• 4U 60-bay
• 4U 90-bay

Dual redundant or single upgradable to dual redundant

Super capacitor + flash module

• Single controller:

  • 4U 40-bay/60-bay: Default DDR4 12GB, up to 192GB
  • 4U 90-bay: Default DDR4 16GB, up to 192GB
  • The other form factors: Default DDR4 8GB, up to 192GB
• Dual redundant controllers:

  • 4U 40-bay/60-bay: Default DDR4 24GB, up to 384GB
  • 4U 90-bay: Default DDR4 32GB, up to 384GB
  • The other form factors: Default DDR4 16GB, up to 384GB

• Onboard host ports:

  • 25GbE (SFP28) x 4, RDMA
• Host board options:

  • 16Gb/s FC x 4
  • 32Gb/s FC x 2
  • 32Gb/s FC x 4
  • 10GbE (SFP+) x 2
  • 25GbE (SFP28) x 2
  • 25GbE (SFP28) x 4
  • 100GbE (QSFP28) x 1, RDMA
  • 100GbE (QSFP28) x 2, RDMA
  • 12Gb/s SAS x 2

• 2.5″ SAS SSD
• 2.5″ 12Gb/s SAS 10,000 RPM HDD
• 3.5″ 12Gb/s NL-SAS 7,200 RPM HDD
• 2.5″ SATA SSD, 3.5″ 6Gb/s SATA 7,200 RPM HDD (for single-controller models only)
• 2.5″ U.2 NVMe SSD (for U.2 SSD cache models; must be purchased from Infortrend)

• Per appliance: 896 (via expansion enclosures)
• Per cluster: 3,584 (via scale-out with other series of appliances)

RAID 0, RAID 1, RAID 3, RAID 5/5F, RAID 6/6F, RAID 10, RAID 30, RAID 50, RAID 60

Inline compression, offline deduplication

• Default software features include:

  • Thin provisioning (block level)
  • Scale-out (file level): 1 appliance per cluster
  • Scale-out (block level): 4 appliances per cluster
  • Snapshot (block level): 64 per source volume, 128 per system
  • Local replication: 4 per source volume, 16 per system
  • Remote replication (file level): support Rsync with 128-bit SSH encryption
• Optional software features require additional license:

  • HA Service (block level, file level)
  • SSD cache (block level, file level)
  • Automated storage tiering: 4 tiers per pool
  • Advanced scale-out (file level): 4 appliances per cluster
  • Advanced snapshot (file level): 1,024 per folder
  • Advanced snapshot (block level): 256 per source volume, 4,096 per system
  • Advanced local replication: 8 per source volume, 256 per system
  • Advanced remote replication (block level): 8 per source volume, 64 per system

• Microsoft Windows Server 2019/2016/2012 R2/2012/2008 R2/2008
• Windows 7 SP1
• Windows 8.1
• Windows Hyper-V
• Red Hat Enterprise Linux
• SUSE Linux Enterprise
• Sun Solaris
• macOS X
• VMware
• Citrix XenServer
• OpenStack Cinder

• File level: CIFS/SMB (version 2.0/3.0), NFS (version 2/3/4), AFP (version 3.1.12), FTP/FXP (vsftp 2.3.4), WebDAV (httpd package 2.4.6)
• Block level: FC, iSCSI, SAS
• Object level: RESTful API

EonCloud Gateway supports integration with the following cloud providers:

• Amazon S3
• Microsoft Azure
• Alibaba Cloud
• Google Cloud
• Baidu Cloud
• Tencent Cloud
• OpenStack
• Wasabi
• Yandex
• hiCloud
• Backblaze Cloud

• Web-based EonOne management software
• User account management
• Group management
• Folder management – folder access control
• Quota management
• Folder encryption with AES
• Integration with Microsoft Active Directory (AD) and Linux LDAP
• Storage Resource Management to analyze history records of resource usage
• Multi-factor authentication login mechanism
• File-level QoS (network traffic control)
• SMI-S standard interface for hypervisor management applications

Email, SNMP traps

Infortrend offers a wide range of applications for common enterprise needs. For detailed information, please refer to the Applications for GS webpage.

JB 3012A, JB 3016A, JB 3024BA, JB 3025BA, JB 3060L, JB 3090

• Immutable object storage
• Hot-swappable hardware modules
• Device mapper
• Antivirus
• Trunk group
• Cache safe technology
• UPS
• WORM (file level only)
• SMB Multichannel

• Safety: UL, BSMI, CB
• Electromagnetic compatibility: CE, BSMI, FCC

• 80 PLUS-certified power supplies delivering more than 80% energy efficiency
• Intelligent multi-level drive spin-down

• Power supplies: redundant and hot-swappable

  • 4U 40-bay/60-bay: 1200W x 2 (80 PLUS Platinum)
  • 4U 90-bay: 1600W x 2 (80 PLUS Titanium)
  • The other form factors: 530W x 2 (80 PLUS Bronze)
• AC voltage:

  • 4U 40-bay/60-bay: 100-127VAC @10A, 200-240VAC @8A
  • 4U 90-bay: 100-127VAC @12A, 200-240VAC @10A
  • The other form factors: 100-240VAC @10-5A
• Frequency: 50-60 Hz

• Power supplies: redundant and hot-swappable

  • 4U 40-bay/60-bay: 1300W x 2 (80 PLUS Titanium)
  • 4U 90-bay: 1600W x 2 (80 PLUS Titanium)
  • The other form factors: 800W x 2 (80 PLUS Titanium)
• AC voltage:

  • 4U 40-bay/60-bay: 100-127VAC @10A, 200-240VAC @8.5A
  • 4U 90-bay: 100-127VAC @12A, 200-240VAC @10A
  • The other form factors: 100-127VAC @10A, 200-240VAC @5A
• Frequency: 50-60 Hz

• Temperature:

  • Operating: 0°C to 40°C without CBM, 0°C to 35°C with CBM
  • Non-operating: -40°C to 60°C
• Altitude:

  • Operating: sea level to 3,048 m (10,000 ft)
  • Non-operating: sea level to 12,192 m (40,000 ft)
• Relative humidity: 5% to 95% non-condensing, operating and non-operating

• Standard service: 3-year limited hardware warranty and 8×5 phone, web, and email support (batteries are covered under warranty for 2 years).
• Warranty extension: standard service can be extended up to 5 years.
• Service upgrade options: the following service can be upgraded to 5 years

  • Upgrade: replacement part dispatch on the next business day.
  • Advanced service: phone, web, and email support + onsite diagnostics on the next business day.
  • Premium service: phone, web, and email support + onsite diagnostics in 4 hours.
• Technical support: installation/maintenance guide, software/firmware download, troubleshooting and support tickets.
• Product services: product registration, licensing service, product repair, and order status.

Without chassis ears and protrusions

• 2U 12-bay: 449 x 88 x 509.8 mm
• 3U 16-bay: 449 x 130 x 509.8 mm
• 4U 24-bay: 449 x 174.6 x 509.8 mm
• 4U 40-bay: 443.2 x 176 x 735.8 mm
• 4U 60-bay: 443.2 x 176 x 849.8 mm
• 4U 90-bay: 435 x 176 x 1088.8 mm

• 2U 12-bay: 588 x 379 x 780 mm
• 3U 16-bay: 588 x 423 x 780 mm
• 4U 24-bay: 588 x 465 x 780 mm
• 4U 40-bay: 625 x 460 x 1032 mm
• 4U 60-bay: 620 x 460 x 1140 mm
• 4U 90-bay: 620 x 500 x 1400 mm

• 4U 24-bay: 44.73 lbs (20.29 kg)
• 4U 40-bay: 59.52 lbs (27 kg)
• 4U 60-bay: 61.73 lbs (28 kg)
• 4U 90-bay: 79.68 lbs (36.14 kg)

• 4U 24-bay: 74.58 lbs (33.83 kg)
• 4U 40-bay: 109.57 lbs (49.7 kg)
• 4U 60-bay: 114.64 lbs (52 kg)
• 4U 90-bay: 156 lbs (70.76 kg)
